What is the Jointmaker Pro?
The Jointmaker Pro is nothing more than an adjustable back saw in a frame. Rather than the blade moving forward and backward as is typical with every handsaw in the world, it is held in place and the stock, rigidly attached to linear tables, is moved over the top of the blade.
The angle of attack is adjustable based upon either the thickness of the material, the width of the material or the hardness of the material, or any combination of the three. What makes the Jointmaker Pro so unusual is that it is a handsaw that is cutting from the bottom up.

PRECISION CUTTING

Blade with high quality
As the core part, the high quality of the blade is the guarantee of cutting performance. If you were to take the blade and put it in a hand saw, it would work just like a dozuki crosscut pull saw. The blade is one of the finest crosscut saws made on this planet, it is patented and each tooth has four separate grinds with 28 teeth per inch (Crosscut A).

Multiple blade types for choice
There are four types of blades, Crosscut A (standard part) is the most commonly used blade, whose kerf is as small as 0.4 mm, and will satisfy most cutting requirement. Crosscut B (optional part), is best for the soft woods; Crosscut C (optional part) is a little wider than Crosscut A, this blade was designed for fret wire, but it is also used for cutting dense woods; Rip Blade (optional part) gives an incredible finish when ripping your stock, it can be used for dovetails making.

NYLON GEAR

The gears are nylon. This is a perfect application for nylon gears. There is no backlash and it is a low-load and low-rpm mechanism.

SLIDING STRUCTURE MOVES SMOOTHLY

The JMPv2 uses cylindrical guide and linear bearing system (sealed bearing), the accuracy of parallelism of all the parts is high. The system needs no adjustment or lubrication (assembled in factory). The operation is easy with lttle noise, which ensures the smooth cutting experience.

Table sliding parallel with blade
The parallelism accuracy of the sliding direction of the table, the blade and the guide rail is very high. The straightness accuracy of the cylindrical guide rail is within 0.025 mm. This parallelism accuracy can complete the fine cutting of the miniature stock.

A clean and tidy cut can be obtained by this sliding system. Even if you put a small piece of paper by the side of blade on the table, then pushing the fence forward and back, you cannot find any gap between the paper and blade at all.

Silent linear bearing, the cutting can be operated by one hand
Linear sealed acetyl bearings provide a sliding process with low friction, which
avoids the clogging caused by dust getting into bearings. The noise is smaller than power tools. The cutting can be completed by one-hand operation.

SIMPLE ADJUSTMENT OF BLADE HEIGHT, ANGLE AND TILTING

The blade height and pitch can be easily adjusted via the keel assembly

The adjustment mechanism of the keel assembly features gears with minimal backlash, which can not only ensure smooth rotation, but also the accurate setting of the blade height and pitch.

The blade can be freely tilted via a trunnion assembly
The blade can be tilted via a trunnion assembly up to 45° by left or right side. The four included stops can set the tilt angle quickly for repeat cutting.

THE WOODEN FENCE AND JAWS

The Fences and Trap Jaws are made of Poplar. The trap jaws can be used to hold the wood stock against fence quickly for cutting accurately. They are consumable items and replacements are available to order or you can make your own.

SPECIAL PROCESSING WITH SELECT MATERIAL

Anodized aluminium sliding table
The sliding tables are made from anodized aluminium, which makes them not only have good anti-friction and high hardness but also the exquisite appearance of matte finishing.

High-hardness cylindrical guide bar
The cylindrical guide is made of 40Cr steel which is T235 hardened and tempered . After chroming, the surface of the guide bar is bright, good-looking, rust proof and hard.

Japanese high quality blade
The Blade Teeth are processed with a high-frequency heat treatment, so that they have high hardness and excellent cutting performance, allowing them to achieve fine cutting on various soft and hard wood.

APPLICATIONS
The Jointmaker Pro v2 is ideal for:
●Box Makers ●Environmentally concerned woodworkers

●Musical Instrument Makers ●Professional Woodworkers

●Architectural Model Makers ●Special Effects Studios ●Toy Makers

●Picture Framers Schools ●Furniture Makers ●Artists

● Parquetry ●Hobbyists ●Model Railroad Set Builders

●Doll house makers ●Model Makers....

THE ONLY LIMIT IS ONE'S IMAGINATION!
